Royal Electric Stacker with EPS
ROYAL FORKLIFT (SUZHOU) CO., LTD.- Cab Location：Rider Type
- Type：Stacker
- Power：AC Motor
- Load Capacity：1t-2.5t
- Fuel：Battery
- Load center：500mm
Base Info
- Model NO.：S15
- Lift height：<6000mm
- Condition：New
- Fork Width：540,570,600,685mm
- Fork Length：1150mm
- Battery：24V 270ah
- Wheel：PU
- Controller：Italy Zapi
- Transport Package：Standard Export Packing
- Specification：CE
- Trademark：Royal
- Origin：China
- HS Code：84271090
- Production Capacity：20000PCS,Year
Description
Basic Info.
Model NO. S15 Lift height <6000mm Condition New Fork Width 540/570/600/685mm Fork Length 1150mm Battery 24V 270ah Wheel PU Controller Italy Zapi Transport Package Standard Export Packing Specification CE Trademark Royal Origin China HS Code 84271090 Production Capacity 20000PCS/YearProduct Description
| Manufacturer | RY | |
| MODEL | S16SL-T | |
| Power Type | battery | |
| Drive type | rider type | |
| capacity | Q(kg) | 1600 |
| Load Centre | c(mm) | 600 |
| wheel base | y(mm) | 1357 |
| self weight | kg | 1390 |
| wheel | PU | |
| drive wheel size | mm | Φ230×70 |
| small wheel size | mm | Φ85×70 |
| balance wheel size | Φ124×60 | |
| wheel quantity D/B/S | 1/1/4 | |
| Mast Lowered Height | h1(mm) | 2080 |
| Rated Lift Height | h3(mm) | 4500 |
| Mast Extended Height (With Backrest) | h4(mm) | 5070 |
| Fork lowered height | h13(mm) | 85 |
| total lenght | l1(mm) | 2078 |
| body lenght withour fork | l2(mm) | 935 |
| total width | b1 b2(mm) | 820 |
| fork sie | s/e/l(mm) | 60/180/1150 |
| Backrest width | b3(mm) | 770 |
| widht of fork outside | b5(mm) | 570 |
| Ground Clearance | m1(mm) | 25 |
| Ground Clearance | m2(mm) | 25 |
| Aisle Width with pallet 1000×1200 | Ast(mm) | 2360 |
| Aisle Width with pallet 800×1200 | Ast(mm) | 2297 |
| Turning Radius (Outside) | Wa(mm) | 1600 |
| Travel Speed (full load/No Load) | km/h | 5.8/6 |
| Lifting Speed (full load/No Load) | mm/s | adjust |
| Lowering Speed (full load/No Load) | mm/s | adjust |
| Max.Gradeability (full load/No Load) | % | 6/12 |
| brake | electromagnetic braking | |
| controller | ZAPI AC | |
| drive motor | KW | 1.7 |
| lift motor | KW | 3.2 |
| turning motor | KW | 0.8 |
| battery | V/Ah | 24/270 |
| battery weight | kg | 288 |
| battery box size | l/w/h | 624/284/627 |
