• Model NO.：FG30
• Lift height：3000~5000mm
• Condition：New
• Fork Size：1070mm*125mm*45mm
• Weight：4220kg
• Engine：Nissan K21
• Color：Decided by Buyer
• Max. Lifting Height：3000mm
• Rated Power：47kw,2250rpm
• Battery：12V,60ah
• Number of Cylinders：4
• Tire：Pneumatic
• Wheel Base：1700mm
• Transport Package：Container
• Specification：2660mm*1225mm*2140mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：800sets,Year

Manufacturer  LTMGModel Power shift T/MFG30Manual shift T/MFG30Load capacity kg3000Load center mm500Power unit  GasolineOperator type  Driver/seatTire typeFront/rear PneumaticWheelFront/rear 2/2Max. lifting height mm3000Free lift mm150Fork sizeL*W*Tmm1070*125*45Tilt rangeMast forward/backwarddeg6/12Overall length(without fork) mm2660Total width mm1225Mast height (fork lowering) mm2075Overall height fork raisedWith backrestmm4250Height to head guard mm2140Turning radius(outside) mm2400Front face of fork to front axle mm480Min. right angle stacking aisle  without load length&clearancemm2880SpeedMax Travelling full/no loadkm/h18/19.5Lifting full/no loadmm/s450/500Lowering full/no load mm/s450/450Max.drawbar pullPower shift T/M full/no loadkg1300/1000Manual shift T/M full/no loadkg1350/1000Gradeability at 1.6km/hPower shift T/M full/no load%17/20Manual shift T/M full/no load%17/20Truck weight kg4220Weight  distributionFull load front/rearkg6390/830No load front/rearkg1650/2570TiresNumberfront/rear2/2Modelfront axle28x9-15-12PRrear axle6.50-10-10PRWheelbase mm1700TreadFront/rearmm1000/970Ground clearanceAt lowest point(mast)mm120Framemm135BrakeService  brake Hydraulic-foot pedalParking brake Mechanical-hand leverBatteryVoltage/capacityV/AH12/60EngineModel Nissan K21Rated powerPS(kw/rpm)47/2250(34.6/2250)Rated torquekg-m    max.(N.m)15.7/1600(153/1600)Number of cylinders 4PlacementL2.065Fuel tank capacityL70TransmissionSpeed forward/backwardPower shift T/M Manual shift T/M1-1 power shift T/M
2-2 power shift T/MOperating pressureHydraulic system pressurekg/cm²180

Product Features

1.The standard LED lamps and warning lights make it safer,more energy efficient and create better working condition.
2.Equipped with USA IMPCO gas system which is more reliable.
3.Thicker reinforcing plate ensures the safety and efficiency.
4.New designed overhead guard protective device prevent the sudden accidents.
5.Equipped with the powerful and efficient EFI,EPA approved engine Nissan K25 with excellent environmental performance;GM engines and Chinese powerful and reliable engines are optional.
