• Model NO.：CPC30E05
• Condition：New
• Rated Loading Capacity：3000kg
• Lifting Height：2 Stage 3m Mast
• Engine：Chinese A495bpg Diesel Engine
• Tire Type：Pneumatic Tire
• Rated Power：42kw,2650rpm
• Fork Lenth：1070mm
• Min.Turning Radius：2340mm
• Unloaded Weight：3490mm
• Gearbox Type：Mechanical
• Overall Dimensions：2675mm*1200mm*2090mm
• Transport Package：Nude
• Specification：CE
• Trademark：Hyundai
• Origin：Jiangsu, China
• HS Code：84272090
• Production Capacity：3000 Sets Per Month

feature
model
CPC30E05
CPCD30E05
Rated load capacity
kg
3000
3000
Load center
mm
500
500
size
STD MAST 2 stage
Fork max. lift height
mm
3000
3000
Fork size
T*W*L
mm
45*125*1070
45*125*1070
Bracket
ISO standard

2 grade
2 grade
Fork distance
MIN.*MAX.
mm
260*1100
260*1100
Mast tilt angle
F/R
deg
6°/12°
6°/12°
Outside size
Total length
mm
3745
3745
width
mm
1200
1200
Mast lowest height
mm
1280
1280
Overhead guard height
mm
2090
2090
Turning radius
Min outside
mm
2340
2340
Min. right angle aisle width
mm
2150
2150
performance
speed
Travel speed(unload)
mm
20
20
Lifting (load)
Mm/s
450
450
Max.gradeability
Speed 1.6km/h()
%
20%
20%
weight
unloaded
Kg
4390
4390
frame
tyres
front

28*9-15-14PRRRRRR
28*9-15-14PR
rear

6.5-10-10PR
6.5-10-10PR
wheelbase
distance
mm
1625
1750
Wheel tread
front
mm
1000
1000
rear
mm
980
980
Ground clearance
At the lowest point
Mm
120
120
drive
battery
Voltage/capacity
v/Ah
12/100
12/100
engine
model

A495BPG
A495BPG
Rated output
Kw/rpm
42/2650
42/2650
Max. engine torque
Kg.m/rpm
17.4/2000-1900
17.4/2000
