Rider Type 1.6 Ton Electric Stacker
ROYAL FORKLIFT (SUZHOU) CO., LTD.- Type：Electric Pallet Truck
- Power：No
Base Info
- Model NO.：S16L-T
- Load Capacity：1-5.0t
- Fuel：Electric
- Load center：>500mm
- Lift height：200mm
- Condition：New
- Package：6 PCS,Pallet
- Width Overall Fork：450,520,540,685 mm
- Fork Length：800,1100,1150,1220,1500,1800,2000
- Color：Yellow,Red,Grey,Blue,Orange
- Certificate：Ce
- Weight Capacity：2t,2.5t,3t,3.5t,5t
- Battery：24V 210ah
- Transport Package：Standard Export Packing
- Specification：2200X700X700MM
- Trademark：Royal
- Origin：China
- HS Code：84279000
- Production Capacity：200000PCS,Year
Description
CharacteristicsManufacturer RY MODEL S16SL-T Power Type battery Drive type rider type capacity Q(kg) 1600 Load Centre c(mm) 600 wheel base y(mm) 1357 self weight kg 1390 wheel PU drive wheel size mm Φ230×70 small wheel size mm Φ85×70 balance wheel size Φ124×60 wheel quantity D/B/S 1/1/4 Mast Lowered Height h1(mm) 2080 Rated Lift Height h3(mm) 4500 Mast Extended Height (With Backrest) h4(mm) 5070 Fork lowered height h13(mm) 85 total lenght l1(mm) 2078 body lenght withour fork l2(mm) 935 total width b1 b2(mm) 820 fork sie s/e/l(mm) 60/180/1150 Backrest width b3(mm) 770 widht of fork outside b5(mm) 570 Ground Clearance m1(mm) 25 Ground Clearance m2(mm) 25 Aisle Width with pallet 1000×1200 Ast(mm) 2360 Aisle Width with pallet 800×1200 Ast(mm) 2297 Turning Radius (Outside) Wa(mm) 1600 Travel Speed (full load/No Load) km/h 5.8/6 Lifting Speed (full load/No Load) mm/s adjustable Lowering Speed (full load/No Load) mm/s adjustable Max.Gradeability (full load/No Load) % 6/12 brake electromagnetic braking controller ZAPI AC drive motor KW 1.7 lift motor KW 3.2 turning motor KW 0.8 battery V/Ah 24/270 battery weight kg 288 battery box size l/w/h 624/284/627
