Mima Electric 3 Way Forklift for Very Narrow Aisle
Banyitong Science & Technology Developing Co., Ltd.- Cab Location：Not Adjustable
- Type：Stacker
- Power：AC Motor
- Load Capacity：1T - 5T
- Fuel：Electric
- Load center：500mm
Base Info
- Model NO.：MC
- Lift height：9000mm
- Condition：New
- Drive Motor：AC Motor
- AC Controller：Curtis
- Max. Lifting Height：9000m
- Max. Loading Capacity：1500kg
- Warranty：12months
- Lift Motor：AC Motor
- Operation Type：Stand on
- Transport Package：Standard Packing
- Specification：SGS, ISO
- Trademark：MiMA
- Origin：China
- HS Code：8427109000
- Production Capacity：1000 Units,Year
Description
3 way forkliftModel MC10 MC15 Operate type stand on stand on Rated capacity kg 1000 1500 Load center mm 500 500 Wheelbase mm 1605 1700 Service weight(incl. battery) kg 4800 5520 Wheel type PU PU Wheel size,load side mm Φ140*100 Φ140*127 Wheel size,drive side mm Φ380*165 Φ380*165 Balance wheel mm Φ204*76 Φ204*76 Number of wheels,front/rear(x=drive) 4/1x+2 4/1x+2 Mast closed height mm 2800 2823 Free lifting height mm 1690 1745 Lifting height mm 4500 4500 Mast height with backrest mm 5584 5555 Overhead guard height mm 2260/2300 2260/2300 Overall length mm 2906 2985 Overall width mm 1450 1550 Fork size mm 1000/125/50 1200/125/50 Turning radius mm 1880 1980 Driving motor(S2-60min) kw 5.5AC 5.5AC Lifting motor(S3 15%) kw 8.6AC 8.6AC Battery voltage/capacity V/Ah 48/400 48/450 Battery weight kg 675 740 Brake type Mechanical Mechanical Steering system EPS EPS
BANYITONG SCIENCE AND TECHNOLOGY DEVELOPING CO., LTD.
Founded in 1994, BANYITONG SCIENCE & TECHNOLOGY DEVELOPING CO.,LTD is located in Hefei, Eastern of China. As the leading manufacturer of Chinese electric forklift and material handling equipment, we are specialized in designing and developing with all-around logistics handling solutions. We have passed not only ISO9001:2008, ISO14001:2004 and CE certifications, but also got the People's Republic of China Special Equipment Production License and the honor of "Innovative Enterprise".
Referring to 12 series and more than 50 kinds of products, MiMA can offer you with electric forklift, electric reach truck, pallet stacker, pallet truck, order picker, tow tractor, narrow aisle forklift, special forklift, AGV and other customized equipments, which can provide customers with logistics handling solutions from 500kg to 100,000kg. Due to serialization and standardization, all MiMA products are widely used in medicine, food, chemical, household electrical appliances, wool cotton textile, tobacco, electronics, machinery, furniture and many other industries.
Owing to 100 national service networks and dozens of foreign dealers, we promise customers with competitive prices and perfect after-sales service. We are looking forward to better cooperation all over the world.
1.Are you factory or trading company?
We are the factory which have been manufacture electric forklift for more than 20 years.
2.What is the delivery time?
Generally it is can delivery immediately if the goods are in stock. Or it is 15-30 days if the goods are out of stock.
3.What is the Payment?
TT(bank transfer), LC at sight or Alibaba , all will be accepted.
4.Is OEM & ODM available?
1). We can do the product according your design
2). We can provide customized solutions according your requirments.
5.Can you provide training for the customer?
Yeah. We can provide training for our customer.
6.What certification do you have?
Our company has passed ISO 9001:2008 and all of the forklift have CE certification.
7.How can I get the best price?
Price is the most concerning problem of every customer,if you want to know the price.We need to know your detailed requirements.
