• Model NO.：cpcy30
• Lift height：3000~5000mm
• Condition：New
• Rated Load：3500kg
• No Fork Length：3550mm
• with Fork Length：4820mm
• Width：1720mm
• Height of The Mast：2120mm
• Height of The Cab：2170mm
• Full Height When Max Lifting：4700
• Ground Clearance：200mm
• Max Lifting Height：4000mm
• Max Speed：37
• Transport Package：Nude Packing
• Specification：3500*1720*2100mm
• Trademark：EOUGEM
• Origin：China Shandong
• HS Code：8427209000
• Production Capacity：3000sets in a Year

ModelForklift CPCY35(with CE)
EngineModelXINCHAI 498 Rated output(kw)37KW TypeIn line,vertical,water cooled,four-stroke Number of cylinders4 Cylinder bore98 Cylinder sroke105 Rated speed(r/min)2200 Method of startingElectric Total displacement (L)3.168Rated load(kg)3500Load center distance(mm)565Lift height(mm)3000The freedom lifts the altitude(mm)150Max lifts the speed(full load)(mm/s)372Gate inclination angle (F/R)(°)6/12Moving velocity (idling)(km/h)19Max climbing power(%)20Overal dimensions(L*W*H)(mm) No fork(mm)3500
With fork(mm) 4650Width (mm)1700Height(mm)2100Dead weight(kg)4700Min ground clearance(mm)206Wheel distance(mm)1320Axle-base(mm)2040


Why choose us?
1). The quality is guaranteed due to strong technical support ,high quality component ,advanced production line and strict quality control system.
2). One-stop service with a large spare parts warehouse and professional service team .No matter where you are, you are guaranteed of eougem warm reception, trustworthy and efficient professional services and persistent care.


Pre-Sales Service
 Inquiry and consulting support in 24 hours.
 View our factory.Drive and test the machine by customers.
 Use trade assurance to ensure customer safety.
After-Sales Service
Training how to instal the machine, training how to use the machine.?
 Engineers available to service machinery overseas.
