• Model NO.：ZJ400D
• Altitude Range：0~2000m
• Voltage Fluctuating：0.7~1.1ue
• Dielectric (Volt) Strength：50Hz 1000V AC 1min
• Current Volt Drop of Main Contact at 100：Not Above 80mv
• Dimensions：104.5X65X106 mm
• Continual Working Duration：8h
• Transport Package：Carton,Pallet
• Specification：104.5x65x106 mm
• Trademark：Huanxin
• Origin：Anhui Hefei
• HS Code：8536419000

Basic Info.

Model NO. ZJ400D Altitude Range 0~2000m Voltage Fluctuating 0.7~1.1ue Dielectric (Volt) Strength 50Hz 1000V AC 1min Current Volt Drop of Main Contact at 100 Not Above 80mv Dimensions 104.5X65X106 mm Continual Working Duration 8h Transport Package Carton/Pallet Specification 104.5x65x106 mm Trademark Huanxin Origin Anhui Hefei HS Code 8536419000

Product Description

Product Description


Overview

The ZJ400D contactor is a SPST (Single Pole Single Throw; normally open type) DC contactor, designed for direct current loads, particularly for motors on small electric vehicles such as light industrial trucks, electric forklift, electric pallet stacker, golf cart, etc. ZJ400D has double breaking main contacts with silver alloy contact tips, which are weld resistant, hard wearing and have excellent conductivity.

Main rated load current of contact circuit (amps):    400A
Dielectric (volt) strength:    50Hz 1000V AC 1min
Current volt drop of main contact at 400A:    Not above 80mV
Dimensions (LxWxH ): 104.5x65x106 mm
Mounting: two 6.5mm fixing holes in bracket; pitch-row: 63mm
Continual working duration: 8h
Mechanical life:    100,000 times
Electric life: 2,000,000 times
Specifications:

Model: ZJ400D
Voltage Options (Volts): 12V, 24V, 36V, 48V or 72V.
Ambient temperature:-25~+40ºC
Altitude range:0~2000m
Max.relative humidity: 90% at 25ºC
Installation method:vetically or horizontally
Voltage fluctuating:0.7~1.1Ue
