• Model NO.：ES20-20RA
• Condition：New
• Name：2000kg Full Electric Stacker(Es16-16ra)
• Drive Unit：Battery
• Tyre Type：PU
• Tyre Size：230X75
• Tread, Operator Side：634mm
• Height, Mast Lowered：2020,2170,2320mm
• Free Lift：100mm
• Lifting Height：4500,4800,5000mm
• Height, Mast Extended：3529mm
• Fork Height, Lowered：85mm
• Transport Package：Seaworthy Packing
• Specification：CE, SGS, ISO
• Trademark：SHYTGER
• Origin：Shanghai, China
• HS Code：84271090
• Production Capacity：3000units,Year

 Characteristics1.1Manufacturer SHYTGER1.2Model designation ES14-14RASES16-16RAST1.3Drive unit BatteryBattery1.4Operator type Rider standRider stand1.5Load capacityQ (kg)140016001.6Load centerc (mm)6006001.8Load distancex (mm)7137131.9Wheelbasey (mm)13941394 Weights2.1Service weight (Incl. battery)kg126012902.2Axle loading, laden operator/load sidekg830/ 1830905/ 19802.3Axle loading, unladen operator/load sidekg805/455820/470 Wheels, Chassis3.1Tyre type PU/ PUPU/ PU3.2Tyre size, operator sidemm230x75230x753.3Tyre size, load sidemm85x7085x703.4Balance wheels (dimensions) 130x60130x603.5Wheels, number operator/load side (x=drive wheels) 1x+ 2/ 41x+ 2/ 43.6Tread, operator sideb 10  (mm)6346343.7Tread, load sideb 11  (mm)380380 Dimensions4.2Height, mast loweredh 1  (mm)2020/2170/23202020/2170/23204.3Free lifth 2  (mm)1001004.4Lift heighth 3  (mm)3000/3300/36004500/4800/50004.5Height, mast extendedh 4  (mm)352935294.9Height of tiller arm in operating position, min/ maxh 14  (mm)1007/ 14121007/ 14124.15Fork height, loweredh 13  (mm)85854.19Overall lengthl 1  (mm)2003/ 25252003/ 25254.20Length to face of forksl 2  (mm)8608604.21Overall widthb 1 / b 2  (mm)8508504.22Fork dimensionss/ e/ l (mm)60/ 190/ 115060/ 190/ 11504.25Outside fork width, minimum/ maximumb 5  (mm)5705704.32Ground clearancem 2  (mm)30304.33Aisle width, 1000×1200 pallet crosswaysAst (mm)252125214.34Aisle width, 800×1200 pallet lengthwaysAst (mm)245424544.35Outer turning radiusWa (mm)16131613 Performance5.1Travel speed, laden/ unladenkm/ h7.4/8.07.4/8.05.2Lifting speed, laden/ unladenm/ s0.10/0.180.10/0.185.3Lowering speed, laden/ unladenm/ s0.17/0.180.17/0.185.8Maximum gradeability, laden/ unladen S 2  5 min.%8/ 168/ 165.10Service brake ElectromagneticElectromagnetic Drive6.1Drive motor rating S 2  60 min.kW1.51.56.2Lift motor rating at S 3  15%kW336.4Battery voltage/ rated capacity (5h)V/ Ah24/ 23024/ 2806.5Battery weight (with box)kg210240 Battery compartment dimensions l/ w/ hmm815/ 208/ 630815/ 208/ 630 Battery type Industry batteryIndustry battery Others8.1Type of drive control AC  ZAPIAC  ZAPI8.4Sound level at operator's eardB (A)74748.5Steering Electric power steeringElectric power steering
