Hydraulic Manual Hand Fork Lift 1000kg Capacity with Excellent Quality
Ningbo Cholift Forklift Co., Ltd.- Cab Location：Standard
- Type：Manual Stacker
- Power：Manual
- Load Capacity：1000kg
- Fuel：Manual
- Load center：500mm
Base Info
- Model NO.：SDA1030
- Lift height：1600-3000mm
- Condition：New
- Fork Width：100mm
- Lifting Height：2500mm
- Rated Loading Capacity：1000kg
- Warranty：1 Year
- Color：as Per Customer′s Request
- Power Souce：hydraulic Oil
- Manufacturer：Ningbo Cholift Forklift Co., Ltd.
- Min. Lifting Height：2080mm
- Mast：Single Mast
- After-Sales Service Provided：Overseas Third-Party Support Available
- Max. Lifting Height：2500mm
- Wheel Material：Nylon
- Certification：CE TUV ISO
- Fork Type：Adjustable Fork
- Fork Length：900mm, 900mm
- Transport Package：Plywood Pallets for Manual Pallet Stacker
- Specification：1000kg,3.0M
- Trademark：CHOLIFT
- Origin：Ningbo, China
- HS Code：84279000
- Production Capacity：1000 Pieces Per Day
Description
Product Descriptiontechnical parameterModel SDA10 SDA15 SDA20 Load capacity/rated load Q(kg) 1000 1500 2000 Load centre distance c (mm) 500 400 400 Tyre size,front mm Φ80*70 Φ80*70 Φ80*70 Tyre size rear mm Φ180*50 Φ180*50 Φ180*50 Lifting height H (mm) 1600/2500/3000 1600/2500/3000 1600 Fork lowered height h (mm) 90 90 90 Most lowered height F (mm) 2080/1830/2080 2080/1830/2080 2080 Groung clearance X (mm) 30 30 30 Turning radius R (mm) 1200 1200 1200
