Warehouse Equipment Paper Roll Clamp
Hangzhou Vanguard Machinery Co., Ltd.- Material:Steel
- Surface Treatment:Painting
- Customized:Customized
- Standard:Standard
- Angle:360 Degree
- Color:White, Black, Grey, Orange, Blue
Base Info
- Model NO.:RCF,RCA
- Short Arms:Fixing or Adjusting Available
- Type:Forklift Attachments
- Load Capacity:1t - 5t
- Power:Hydraulic
- Transport Package:Steel Pallet
- Specification:CE, ISO
- Trademark:MIK
- Origin:China
- HS Code:8431209000
Description
ClassOpening Range Long Arm(A) Short Arm Length(B) CGV CGH ET Service Weight (mm) (mm) (mm) (mm) (mm) (mm) (kg) 1300 RCF-20M-A01 2 330-1150 685 515 330 216 138 345 1200 RCF-20M-A02 2 410-1300 790 580 330 222 138 345 2000 RCA-25M-A/B01 2/3 250-1300 824 570 345 295/330 210/250 730/748 2000 RCF-25M-A/B01 2/3 630-1300 824 570 345 290/325 210/250 720/738 2000 RCA-25M-A/B02 2/3 350-1600 956 774 345 310/320 210/250 838/848 2000 RCF-25M-A/B02 2/3 630-1600 956 774 345 308/318 210/250 826/836 1700 RCF-35M-B01 3 680-1830 1130 930 345 458 210/250 950 1700 RCA-35M-B01 3 380-1830 1130 930 345 460 210/250 965 2700 RCF-50M-B/C01 3/4 520-1300 850 590 445 270/290 210/250 820/840 2700 RCA-50M-B/C01 3/4 250-1300 850 590 445 270/290 210/250 835/855 2700 RCF-50M-B/C02 3/4 560-1520 970 690 445 305/322 210/250 880/900 2700 RCA-50M-B/C02 3/4 255-1520 970 690 445 305/322 210/250 898/918 2300 RCF-50M-B/C03 3/4 680-1830 1125 825 450 352/372 210/250 995/1016 2300 RCA-50M-B/C03 3/4 380-1830 1125 825 450 352/372 210/250 1018/1040 1. Eaton powerful hydraulic motor and Heavy duty gearbox provide superior service life.2. All clamps are designed for heavy duty even in the toughest environments.3. All clamps are designed for easy maintenance with less service cost.
4. A variety of contact pads and accessories are available for your different working conditions.
5. 2 pieces of truck auxiliary valves are necessary. 140bar≤ Working Pressure ≤180bar.
6. Fitting Screw M18X1.5-74°(concave); Recommended Hydraulic Pipe internal diameter = 10mm.
